LADEN CONTAINER HANDLING LIFT TRUCKS

TECHNICAL SPECIFICATIONS

LADEN CONTAINER HANDLING LIFT TRUCKS
Model FH45.4
Attachment type 20’/40′ Top Pick Spreader
Attachment mounting on inverted forks
Capacity on tires kg 35.000
Load centre distance (+/- out/in rach) mm 1.300 (+/- 100)
Load centre to centre of front axle mm 2.480
Lifting height under twist-lock mm 9.000
Stacking Ability – containers 1 over 3 = 4 x 9’6”
Wheelbase mm 5.750
Service weight – unladen kg 68.800
EU Stage 3a Engine make&model (Rated Power) (kW) CUMMINS QSM11 (250)
EU Stage 4 Engine make&model (Rated Power) (kW) SCANIA DC13 (257)
Transmission make&model DANA TE32
Service Brakes Wet Disk on front wheels
Tires size 18.00-25
Overall width mm 4.185
Overall length (including spreader) mm 10.785
Overall height (mast lowered) mm 8.650
Seat height mm 2.400
Mast tilt deg 3 / 5
Spreader side-shift mm +400 / -400
Spreader hydraulic (mechanic) pile slope deg 2 / 2

∗ optional

LADEN CONTAINER HANDLING LIFT TRUCKS
Model FH50.5
Attachment type 20’/40′ Top Pick Spreader
Attachment mounting gantry mount
Capacity on tires kg 40.000
Load centre distance (+/- out/in rach) mm 1.700 (+/- 120)
Load centre to centre of front axle mm 2.616
Lifting height under twist-lock mm 15.000
Stacking Ability – containers 1 over 4 = 5 x 9’6”
Wheelbase mm 6.500
Service weight – unladen kg 73.000
EU Stage 3a Engine make&model (Rated Power) (kW) CUMMINS QSM11 (250)
EU Stage 4 Engine make&model (Rated Power) (kW) SCANIA DC13 (257)
Transmission make&model DANA TE32
Service Brakes Wet Disk on front wheels
Tires size 18.00-25
Overall width mm 4.700
Overall length (including spreader) mm 11.460
Overall height (mast lowered) mm 9.100
Seat height mm 2.900
Mast tilt deg 3 / 5
Spreader side-shift mm +300 / -300
Spreader hydraulic (mechanic) pile slope deg 4 / 4

∗ optional

LADEN CONTAINER HANDLING LIFT TRUCKS
Model FH50.6
Attachment type 20’/40′ Top Pick Spreader
Attachment mounting gantry mount
Capacity on tires kg 40.000
Load centre distance (+/- out/in rach) mm 1.700 (+/- 120)
Load centre to centre of front axle mm 2.616
Lifting height under twist-lock mm 17.900
Stacking Ability – containers 1 over 5 = 6 x 9’6”
Wheelbase mm 6.500
Service weight – unladen kg 76.000
EU Stage 3a Engine make&model (Rated Power) (kW) CUMMINS QSM11 (250)
EU Stage 4 Engine make&model (Rated Power) (kW) SCANIA DC13 (257)
Transmission make&model DANA TE32
Service Brakes Wet Disk on front wheels
Tires size 18.00-33
Overall width mm 4.700
Overall length (including spreader) mm 11.460
Overall height (mast lowered) mm 10.600
Seat height mm 2.900
Mast tilt deg 3 / 5
Spreader side-shift mm +300 / -300
Spreader hydraulic (mechanic) pile slope deg 4 / 4

∗ optional
